Adding webdav to docker-compose grafana stack for image previews

It’s quite easy since Grafana containers already have the respecting parameters you only need 3 files and 1 crontab entry.

Grafana CPU Graph example with webDAV-Rendering

modify your docker-compose.yml like this

  grafana-render:
    hostname: grafana-render
    image: grafana/grafana-image-renderer:latest
    ports:
      - "127.0.0.1:8081:8081"

#        - ./data/graphite.htpasswd:/etc/nginx/.htpasswd
  grafana:
#    image: grafana/grafana:4.2.0
    image: grafana/grafana:4.6.5
    ports:
      - "127.0.0.1:3000:3000"
    volumes:
      - ./data/grafana:/var/lib/grafana
#    links:
#        - graphite
    environment:
      - GF_EXTERNAL_IMAGE_STORAGE_PROVIDER=webdav
      - GF_EXTERNAL_IMAGE_STORAGE_PUBLIC_URL=https://my.domain.lan/grafana-uploads/media
      - GF_EXTERNAL_IMAGE_STORAGE_PUBLICURL=https://my.domain.lan/grafana-uploads/media
      - GF_EXTERNAL_IMAGE_STORAGE_WEBDAV_PUBLICURL=https://my.domain.lan/grafana-uploads/media
      - GF_EXTERNAL_IMAGE_STORAGE_WEBDAV_PUBLIC_URL=https://my.domain.lan/grafana-uploads/media
      - GF_EXTERNAL_IMAGE_STORAGE_WEBDAV_URL=http://webdav.my.domain.lan/media
      - GF_EXTERNAL_IMAGE_STORAGE_WEBDAV_USERNAME=grafana
      - GF_EXTERNAL_IMAGE_STORAGE_WEBDAV_PASSWORD=PassSharedGrafanaWebdav_CHANGE_ME
      - GF_RENDERING_SERVER_URL=http://grafana-render:8081/render
      - GF_SERVER_ROOT_URL=https://my.domain.lan
      - GF_SECURITY_ADMIN_PASSWORD=N0B0dyKnows_You_SHOULD_CHANGE_ME
      - GF_SMTP_ENABLED=true
      - GF_SMTP_HOST=smtp.mydomain.lan
      - GF_SMTP_USER=sensors@mydomain.lan
      - GF_SMTP_PASSWORD=mySMTP_PASSWORD_You_SHOULD_CHANGE_ME
      - GF_LOG_FILTERS=rendering:debug

    restart: unless-stopped

  webdav.my.domain.lan:
    restart: unless-stopped
    hostname: webdav.my.domain.lan
    container_name: webdav.my.domain.lan
    build:
      context: ./
#      dockerfile: Dockerfile-alternate
      dockerfile: Dockerfile.webdav
    ports:
      - "127.0.0.1:8008:80"
    volumes:
      - "/opt/docker-compose/general/myproject_services/my.domain.lan/uploads/grafana-uploads/:/media"
    environment:
      USERNAME: grafana
      PASSWORD: PassSharedGrafanaWebdav_CHANGE_ME

create Dockerfile.webdav

FROM thefoundation/upgraded-operating-systems:ubuntu-bionic
RUN ln -s /usr/share/zoneinfo/Europe/Berlin
RUN apt-get update && apt-get install -y nginx nginx-extras apache2-utils

VOLUME /media
EXPOSE 80
COPY webdav.conf /etc/nginx/conf.d/default.conf
RUN rm /etc/nginx/sites-enabled/*

COPY entrypoint-webdav.sh /
RUN chmod +x entrypoint-webdav.sh
CMD /entrypoint-webdav.sh && nginx -g "daemon off;"

create entrypoint-webdav.sh

#!/bin/bash

if [[ -n "$USERNAME" ]] && [[ -n "$PASSWORD" ]]
then
    htpasswd -bc /etc/nginx/htpasswd $USERNAME $PASSWORD
    echo Done.
else
    echo Using no auth.
    sed -i 's%auth_basic "Restricted";% %g' /etc/nginx/conf.d/default.conf
    sed -i 's%auth_basic_user_file htpasswd;% %g' /etc/nginx/conf.d/default.conf

find the folder of your webdav-images ( docker-compose config ) and add a cron entry

#Grafana webDAV cleanup
15 */2  * * *   find /opt/docker-compose/general/my_services/my.grafana.lan/uploads/grafana-uploads/media -type f -name "*.png" -mtime +2 -delete &>/dev/null || true

setup your grafana to include the images
have fun
